Advanced Multi-FunctionBatteryMaintenanceSystem: ZX-3932StorageBattery Activator

The ZX-3932 Storage Battery Activator represents a comprehensive, programmable solution for the testing, maintenance, and restoration of storage batteries. Designed as an all-in-one workstation for technical professionals, it integrates critical functions—charging, discharging, activation, internal resistance, and performance testing—into a single, portable unit. Its programmable logic and robust safety protections make it an essential tool for ensuring battery reliability and longevity across various voltage standards (2V, 6V, 12V), both online and offline.

Core Features & Operational Advantages

1.Programmable Control & Automation: All charging and discharging processes are software-controlled with high precision. Operations automatically terminate upon reaching set parameters or in case of system overheating, enhancing safety and consistency.

2.Comprehensive Maintenance Functions: The device supports routine maintenance tasks, including capacity testing through discharge cycles and battery revival via controlled activation sequences, addressing sulfation and capacity loss.

3.Intelligent Thermal Management: Equipped with integrated temperature monitoring (range: -18°C to 30°C). A temperature-controlled exhaust fan activates automatically when thresholds are exceeded, ensuring stable operation within defined environmental limits.

4.Advanced Three-Stage Charging: Implements a multi-phase charging algorithm (bulk, absorption, float) to optimize battery acceptance and prevent overcharging, thereby extending battery life.

5.Modular Design & Serviceability: Built with a modular architecture, simplifying troubleshooting, component replacement, and future upgrades, which minimizes downtime.

6.User-Friendly Interface: Features a large 480x800 LCD screen providing clear visualization of parameters, real-time data, and system status, facilitating straightforward operation and data interpretation.

Technical Specifications

The ZX-3932 delivers high accuracy across its operational ranges, as detailed below:

1.Charging/Discharging Current:

2V Mode: 1 – 100 A, Resolution: 0.01A, Accuracy: ±0.20%

6V Mode: 1 – 60 A, Resolution: 0.01A, Accuracy: ±0.20%

12V Mode: 1 – 30 A, Resolution: 0.01A, Accuracy: ±0.20%

2.Voltage Range & Accuracy:

2V Mode: 1.7V – 2.6V, Resolution: 0.001V, Accuracy: ≤ ±0.2%

6V Mode: 5.1V – 7.2V, Resolution: 0.01V, Accuracy: ≤ ±0.2%

12V Mode: 10.2V – 15.0V, Resolution: 0.01V, Accuracy: ≤ ±0.2%

3.General Specifications:

Power Supply: AC 220V ±10%

Dimensions: 300 (W) x 425 (D) x 200 (H) mm

Weight: 15 kg

Operating Environment: 0°C to 50°C, 5% to 90% Relative Humidity (Non-condensing)

Cooling Method: Forced Air Cooling

Communication Interfaces: Standard RS232 & USB (customizable options available)

Design: Portable form factor

Conclusion

The ZX-3932 Storage Battery Activator is engineered for technicians requiring precision, reliability, and versatility in battery maintenance. Its combination of programmable multi-function testing, stringent safety protocols—including voltage limiting and automated thermal control—and a clear user interface establishes it as a professional-grade instrument. Suitable for workshop or field use, it effectively supports diagnostic routines, preventive maintenance, and recovery procedures for a wide array of battery types, ensuring optimal performance and durability.
