Advanced Portable Detection: The XP-1A SF6 and Halogen Gas Leak Detector
For technicians and maintenance professionals across utilities, manufacturing, and industrial sectors, identifying gas leaks quickly, accurately, and safely is a critical task. The XP-1A Hand-held SF6 Gas Leak Detector presents a robust and highly sensitive solution designed for field use, targeting not only sulfur hexafluoride (SF6) but also a wide range of halogenated refrigerants.
Primary Applications
This versatile instrument is engineered for leak detection in equipment containing SF6 and other halogen gases. Its use cases span essential industries:
1.Electric Power Utilities: Critical for inspecting SF6-insulated circuit breakers, GIS (Gas Insulated Switchgear), and other high-voltage equipment.
2.HVAC&R Service: Detects leaks of HFC, CFC, and HCFC refrigerants in air conditioning and refrigeration systems.
3.Broad Industrial Maintenance: Applicable in petrochemical plants, railway systems, mining operations, fire suppression system checks, and specialized research facilities.
Key Technical Features and Advantages
The XP-1A is designed with practical, user-centric features that enhance reliability and efficiency in the field:
1.High Sensitivity & Rapid Response: With an ultimate sensitivity of <3 g/year and an instantaneous response time, it pinpoints even minute leaks. An internal, efficient pump actively draws in samples, reducing lag and improving detection speed.
2.Durability and Contamination Resistance: The probe features a reset function that prevents sensor "poisoning" or saturation from large, sudden releases of gas, ensuring continued operation without immediate recalibration. It maintains performance in polluted atmospheres.
3.Intuitive Operation & Flexibility: A 7-level sensitivity adjustment allows adaptation to various background conditions. The probe incorporates a 35.5cm long, flexible stainless steel tip to access confined or difficult areas. Visual (18-level LED indicator) and audible alerts provide clear leak severity feedback.
4.Ready-to-Use Convenience: The instrument requires no calibration, has a short warm-up time of approximately 2 seconds, and features a quick 1-second sensor reset, maximizing productive work time.
Technical Specifications at a Glance
Parameter | Specification |
Detection Method | Mechanical Pump Style (Active Sampling) |
Target Gases | SF6, HFCs, CFCs, HCFCs |
Probe Length | 35.5 cm (Flexible Stainless Steel) |
Ultimate Sensitivity | < 3 grams per year |
Response / Reset Time | Instantaneous / 1 second |
Warm-up Time | ~2 seconds |
Leak Indication | 18-level LED Bar, Audible Alarm |
Sensitivity Adjustment | 7 Levels |
Operating Temperature | 0°C to 52°C (32°F to 125°F) |
Power Supply | 3V DC (Two "C" Cell Alkaline Batteries) |
Battery / Sensor Tip Life | ~30 hours / ~20 hours (approx.) |
Weight & Dimensions | 560g; 22.9 x 6.5 x 6.5 cm |
Compliance | CE, SAE J1627 |
Summary
The XP-1A Hand-held SF6 Gas Leak Detector is a purpose-built diagnostic tool that combines high sensitivity with operational ruggedness. Its design prioritizes quick deployment, resilience in challenging environments, and clear fault indication, making it a reliable choice for technicians tasked with maintaining the integrity of gas-filled systems. The extended probe life and straightforward maintenance requirements contribute to a lower total cost of ownership and consistent performance in preventive maintenance and troubleshooting roles.
